2006 Mitsubishi Lancer Evolution IX
Shadow Circuit Armada takes the Evo IX—already a homologation weapon—and drags it into the 1980s endurance paddock. The familiar greenhouse and door cuts stay as the anchor, but everything around them becomes Group C logic: a wedge nose, sealed front arches, and a longtail deck that looks like it was shaped in a wind tunnel at 3 a.m. It’s the kind of “works prototype” that would have made purists furious and engineers proud.
This isn’t a cartoon widebody. The covered wheels, venturi-style ducting, and long rear overhang are all aimed at the same goal: stability at sustained speed, clean cooling paths, and downforce you can actually lean on. Matte carbon and exposed metallic aero hardware keep it honest—more test session than show stand.
Release Image Studies
Image studies from every angle.
Comparison Shots
Blueprint / Collector Archive
Engineering Artifacts
The technical study and collectible interpretation of one build, preserved together.
02
Shadow Circuit Armada Collector EditionCollector artifact
A presentation-grade collector artifact created for this release and preserved as part of the Widebody Syndicate archive.
Selected archive goods are available for collectors.
2006 Mitsubishi Lancer Evolution IX Shadow Circuit Armada Collectible Poster
Price range: $18.00 through $25.00
2006 Mitsubishi Lancer Evolution IX Shadow Circuit Armada Blueprint Poster
Price range: $18.00 through $25.00
2006 Mitsubishi Lancer Evolution IX Shadow Circuit Armada Framed Collectible Poster
Price range: $37.00 through $75.00
2006 Mitsubishi Lancer Evolution IX Shadow Circuit Armada Framed Blueprint Poster
Price range: $37.00 through $75.00
Technical Dossier
▧
Platform
2006 Mitsubishi Lancer Evolution IX
The 2006 Mitsubishi Lancer Evolution IX is a peak example of the wild spirit and functional precision behind Japan's most revered street-legal rally beasts. Built on a sharp, purposeful platform with a turbocharged inline-four and all-wheel drive, the Evo IX blends a lightweight, rigid chassis with sophisticated electronics and suspension tuning to deliver brutal handling and relentless forward drive. Its purposeful silhouette, aerodynamic efficiency, and motorsport-derived engineering make it a cornerstone for customizers and tuners who seek a raw yet refined platform that rewards both skilled driving and creative modification.
⌘
Aero Package
Extended wedge front bumper with ~1600mm splitter projecting ~180mm and dual vertical dive planes
Hood wedge with recessed NACA ducts feeding auxiliary radiators and pressure-managed extraction
Roof fairing extension and roof intake feeding a top-mounted intercooler for stable charge temps at speed
Longtail underbody diffuser extending ~280mm rearward with five strakes and integrated 80mm diffuser lip
⟡
Chassis
Rendered at dusk on a European endurance circuit, the car reads like a pit-lane rumor made real: longtail taper, covered wheels, and a low, calm attitude in the fast sections. The lighting and matte carbon finish emphasize surface transitions and aero hardware—exactly the details you’d study walking the paddock after qualifying.
◎
Wheels & Tires
BBS Motorsport LM Pro forged monoblocks: 18x11 front
18x12 rear
Aero disc covers with vented side panels for brake heat management
Michelin Pilot Sport Cup 2: 275/35ZR18 front
315/30ZR18 rear
Expanded track: +280mm front
+310mm rear; static ride height target ~45mm with adaptive damping
▤
Powertrain
Built 4G63 2.0L turbo retained for identity
tuned for sustained load rather than peak dyno numbers
Front-mid layout concept to improve weight distribution and reduce understeer under aero load
High-efficiency charge cooling via roof-fed top-mount intercooler and dedicated ducting
Side-exit exhaust outlets to preserve diffuser flow and reduce rear heat soak
△
Fabrication Notes
Carbon widebody and wheel covers require quick-release service strategy for tire changes and brake inspection
Internal ducting bonded to arch covers with sealed interfaces to prevent pressure bleed at speed
Longtail structure tied into rear chassis points with lightweight subframe extensions to control vibration
Splitter and diffuser mounted on hard points with replaceable wear surfaces for track use
×
Design Philosophy
Shadow Circuit Armada takes the Evo IX—already a homologation weapon—and drags it into the 1980s endurance paddock. The familiar greenhouse and door cuts stay as the anchor, but everything around them becomes Group C logic: a wedge nose, sealed front arches, and a longtail deck that looks like it was shaped in a wind tunnel at 3 a.m. It’s the kind of “works prototype” that would have made purists furious and engineers proud.
This isn’t a cartoon widebody. The covered wheels, venturi-style ducting, and long rear overhang are all aimed at the same goal: stability at sustained speed, clean cooling paths, and downforce you can actually lean on. Matte carbon and exposed metallic aero hardware keep it honest—more test session than show stand.
