R030
Swamp Assault Bog Spec
2010 Kia Soul
The Swamp Assault Bog Spec transforms the unassuming 2010 Kia Soul into a purpose-built wetland warrior, engineered for maximum traction and water fording capability. Its widebody conversion features thick tubular composite fender flares with integrated mesh guards to prevent clogging from debris, while the raised static ride height and widened track accommodate massive 345/65 R17 mud-terrain tires. Reinforced armor panels and a snorkel-equipped front bumper ensure reliable performance in deep, muddy conditions without sacrificing engine cooling or protection.
This build blends tactical utility with subtle design cues, featuring a matte hunter green paint layered with black armored accents and a light camo pattern mimicking marsh vegetation. The suspension’s long-travel coil-overs and reinforced control arms are paired with beadlocked Fifteen52 Tarmac wheels, delivering rugged off-road capability with a stance that balances aggression and function. Every detail, from the raised inspection hatch on the hood to the extended rear hatch with integrated LED work lights, is engineered for practical durability in the harshest swampland environments.
Share
Supplementary Photography
4 archive details · swipe / tap to inspectBlueprint / Collector Archive
Engineering record. Exhibition artifact.
The technical study and collectible interpretation of one build, preserved together.
Technical Dossier
▧
Platform
2010 Kia Soul
The 2010 Kia Soul burst onto the scene as a unique and bold alternative in the compact crossover segment. With its boxy silhouette and upright stance, the Soul blends practicality with an urban edge, offering versatile interior space and a straightforward, no-nonsense design foundation. Its unpretentious yet distinctive shape serves as a raw canvas for creative automotive expression without leaning into flashy or aggressive cues.
⌘
Aero Package
Reinforced flat vertical front bumper plate with integrated snorkel air intake
Low-profile continuous rear lip spoiler 60mm high across hatch width
Mesh debris guards inset 30mm within front arches to prevent clogging
Extended splash guards below rear bumper to minimize mud spray
⟡
Chassis
The elevated 210mm static ride height combined with significantly widened front (+185mm) and rear (+190mm) tracks improve stability and ground clearance. This configuration supports aggressive mud-terrain tires and long-travel suspension, allowing confident navigation over uneven, waterlogged ground while maintaining composure in deep ruts and soft surfaces.
◎
Wheels & Tires
Fifteen52 Tarmac beadlock wheels, 17x9 front and 17x10 rear, matte black finish
345/65 R17 mud-terrain tires with deep aggressive tread
Deep offset wheels to clear reinforced suspension components
Beadlock rings for tire retention in low-pressure off-road use
▤
Powertrain
Minor drivetrain reinforcement focused on transfer case with low-range tuning
Snorkel-fed air intake system with ducting shielded under side fenders
Internal radiator shields to protect cooling system in water and debris
Engine tuning prioritizes torque delivery over peak power for bog traversal
△
Fabrication Notes
Widebody panels fabricated using thick tubular composite materials for durability and weight savings
Custom mesh guards integrated into arches with 30mm inset for debris rejection
Reinforced control arms and long travel coil-overs fitted with mud shielding plates
Flat vertical front bumper plate designed for impact resistance and snorkel integration
×
Design Philosophy
The Swamp Assault Bog Spec transforms the unassuming 2010 Kia Soul into a purpose-built wetland warrior, engineered for maximum traction and water fording capability. Its widebody conversion features thick tubular composite fender flares with integrated mesh guards to prevent clogging from debris, while the raised static ride height and widened track accommodate massive 345/65 R17 mud-terrain tires. Reinforced armor panels and a snorkel-equipped front bumper ensure reliable performance in deep, muddy conditions without sacrificing engine cooling or protection.
This build blends tactical utility with subtle design cues, featuring a matte hunter green paint layered with black armored accents and a light camo pattern mimicking marsh vegetation. The suspension’s long-travel coil-overs and reinforced control arms are paired with beadlocked Fifteen52 Tarmac wheels, delivering rugged off-road capability with a stance that balances aggression and function. Every detail, from the raised inspection hatch on the hood to the extended rear hatch with integrated LED work lights, is engineered for practical durability in the harshest swampland environments.
