Story

Rosso Rampante Protocol treats the 2010 F-150 Platinum like a cab-forward silhouette that accidentally wandered into Maranello’s wind tunnel and refused to leave. The stance is the headline—95mm ride height, +190mm track, and a widebody that’s measured like a race part: +180mm up front with a chamfered lip and a long concave relief to calm front-wheel wake, then +230mm rear haunches with heat-evac louvers that read more 458 than work truck.

The trick is keeping it believable: the cabin shifts rearward 85mm and the wheelbase stretches 85mm to make mid-engine packaging and cooling make sense without losing the F-150’s roofline and proportions. Rosso Corsa candy over carbon accents does the rest—show-car clean, but with surfaces and openings that look like they were argued over by aero and thermal engineers, not stylists.

Blueprint

The Whitepaper Room

Inspect drawing ↗Open blueprint study →

Technical dossier

Fictional engineering concept

Platform

2010 Ford F-150 Platinum

Powertrain concept

Longitudinal mid-mounted 5.7L twin-turbo V8 targeting ~820hp with conservative boost for heat control
7-speed dual-clutch with rear transaxle layout for improved polar moment and traction
Side NACA ducts feeding intercooler/radiator arrays ahead of rear wheels with defined exit via quarter louvers
High-flow exhaust routed rearward to twin rectangular outlets with heat shielding around haunch structures

Aero package

Carbon front splitter extending 140mm with twin dive planes rising 90mm
Side skirts extending 90mm outward with a sharp aero shelf and 20mm down-angled rear edge
Rear diffuser 270mm deep with six strakes (40mm thick
180mm tall) and 110mm clearance target
Fixed dual-element rear wing (1680mm) on swan-neck pylons rising 880mm above the rear deck
740mm roof scoop with radiused entry lips feeding rear cooling ducts

Chassis & stance

2010 Ford F-150 Platinum

Wheels & tires

21x11 OZ Racing Ultraleggera forged
matte black centers with polished lips
315/30ZR21 Pirelli P Zero Corsa square setup for neutral balance on widened track
Track widened +190mm front and rear (hub-to-hub) to match widebody geometry

Fabrication notes

Carbon hood with raised intake and extraction vents designed around pressure zones
not symmetry alone
Widebody quarters require inner tub rework and suspension pick-up validation for +190mm track
Underbody sealing and diffuser mounting tied into chassis rails to prevent aero load deflection
Cooling ducting modeled as a continuous path: inlet area
core face area
and controlled exit to avoid heat soak
