Technical DrawingBlueprint archive
R053
Gridiron Juggernaut
2017 Nissan Rogue
The Gridiron Juggernaut transforms the 2017 Nissan Rogue into a formidable endurance race machine, marrying SCCA Trans-Am muscle car ethos with the practicality of an SUV. Its 180mm widebody flares with integrated cooling louvers and side exhausts push the envelope of functional design, creating a broad, aggressive stance that channels raw American power through a Japanese chassis. Under the hood sits a naturally aspirated LS7 7.0L V8, paired with race-tuned headers and a bespoke cooling system to sustain high-rev endurance runs.
This build balances muscle and precision with a heavy-duty front splitter, canards, and a large rear diffuser feeding a fixed steel wing, engineered for aerodynamic stability over long stints. The reinforced aluminum rear hatch and dual center exhaust tips add both durability and a purposeful race-ready aesthetic. On track, the moderate 110mm ride height paired with 18x12 American Racing Torq Thrust wheels wrapped in Hoosier R7 rubber delivers a planted, muscular stance optimized for sustained cornering and high-speed stability.
Share
Supplementary Photography
4 archive details · swipe / tap to inspectBlueprint / Collector Archive
Engineering record. Exhibition artifact.
The technical study and collectible interpretation of one build, preserved together.
Technical Dossier
▧
Platform
2017 Nissan Rogue
The 2017 Nissan Rogue stands as a pivotal player in the compact crossover segment, blending everyday practicality with a refined driving experience that resonates beyond typical family haulers.
Built on Nissan’s versatile CMF (Common Module Family) platform, the 2017 Rogue balances sleek, aerodynamic styling with a spacious, tech-forward interior. Its chassis architecture supports a smooth ride and confident handling, making it a favorite among urban drivers and outdoor enthusiasts alike. The Rogue’s efficient powertrains and advanced safety features underscore Nissan’s commitment to modern versatility without sacrificing driver engagement. This platform laid the groundwork for a crossover that’s as at home on city streets as it is on weekend adventures.
⌘
Aero Package
Heavy-duty front splitter with canards
Large rear diffuser feeding fixed steel rear wing
Low-mounted large flat rear wing on rear hatch
⟡
Chassis
Designed for long-distance endurance sprints, the Gridiron Juggernaut excels on circuits demanding sustained high speeds and robust handling. Its aerodynamic package provides downforce stability, while the wide track and sticky Hoosier tires offer confident grip through fast sweepers and tight corners alike, making it a competitive contender in pro-level endurance racing.
◎
Wheels & Tires
18x12 inch American Racing Torq Thrust wheels
315/40R18 Hoosier R7 race tires
▤
Powertrain
7.0L naturally aspirated LS7 V8 crate engine swap
Race-tuned headers
Upgraded cooling system for endurance reliability
△
Fabrication Notes
Custom widebody flares fabricated with integrated cooling louvers
Aluminum rear hatch panel reinforced for structural rigidity
Steel fixed rear wing mounted low for optimal downforce balance
Recessed side exhausts routed behind rear arches for packaging
×
Design Philosophy
The Gridiron Juggernaut transforms the 2017 Nissan Rogue into a formidable endurance race machine, marrying SCCA Trans-Am muscle car ethos with the practicality of an SUV. Its 180mm widebody flares with integrated cooling louvers and side exhausts push the envelope of functional design, creating a broad, aggressive stance that channels raw American power through a Japanese chassis. Under the hood sits a naturally aspirated LS7 7.0L V8, paired with race-tuned headers and a bespoke cooling system to sustain high-rev endurance runs.
This build balances muscle and precision with a heavy-duty front splitter, canards, and a large rear diffuser feeding a fixed steel wing, engineered for aerodynamic stability over long stints. The reinforced aluminum rear hatch and dual center exhaust tips add both durability and a purposeful race-ready aesthetic. On track, the moderate 110mm ride height paired with 18x12 American Racing Torq Thrust wheels wrapped in Hoosier R7 rubber delivers a planted, muscular stance optimized for sustained cornering and high-speed stability.
