Dakar Zephyr
1999 Nissan Skyline GT-R R34
The Dakar Zephyr transforms the iconic 1999 Nissan Skyline GT-R R34 into a rugged desert warrior, purpose-built for the relentless challenges of Dakar-style rally raids. Extensive widebody modifications include massive 190mm front and 230mm rear fender flares, designed to house oversized 350/85 R17 rally tires on beadlock wheels, while reinforced composite bumpers and underbody skid plates provide vital protection against harsh terrain. The chassis is stretched with a 160mm extended wheelbase to accommodate a rear transaxle sequential gearbox and robust armored underbody, enhancing both durability and drivetrain packaging for endurance racing.
Under the hood, the RB26 engine is reinvented as a dry sump turbocharged unit with upgraded cooling fed by distinctive roof scoops and sidepod radiators nestled inside the expanded arches. The suspension is lifted to a 290mm ride height with rally-spec Öhlins dampers to maximize travel and absorption over uneven surfaces. Aerodynamically, the car eschews conventional wings for a functional 280mm roof spoiler integrated into a raised rear canopy, which also houses a spare tire and rally telemetry antennas, balancing airflow stability with practical rally utility.
Share
Supplementary Photography
4 archive details · swipe / tap to inspectBlueprint / Collector Archive
Engineering record. Exhibition artifact.
The technical study and collectible interpretation of one build, preserved together.
Technical Dossier
▧
Platform
1999 Nissan Skyline GT-R R34
The 1999 Nissan Skyline GT-R R34 is the zenith of Japanese performance engineering from the golden era of the late '90s. With the iconic RB26DETT twin-turbocharged inline-six engine under the hood, it delivers a blend of raw power and precise control, thanks to its advanced ATTESA E-TS all-wheel-drive system and Super-HICAS four-wheel steering. The R34's aggressive yet functional design has become a cultural icon, setting the standard for precision, performance, and tunability that still resonates deeply within the tuner and motorsport communities worldwide.
⌘
Aero Package
280mm tall lightweight roof spoiler integrated with rear canopy
Raised center hood scoop and twin forward ramp vents for enhanced cooling
300mm diffusive aero shelf on rear bumper housing recovery hooks
⟡
Chassis
With an extended wheelbase and widened track supported by massive beadlock wheels and oversized rally tires, the Dakar Zephyr delivers stability and traction over loose sand, rocks, and uneven desert surfaces. The raised ride height and rally-spec Öhlins dampers offer substantial suspension travel, absorbing harsh impacts while maintaining composure at high speeds across challenging terrain.
◎
Wheels & Tires
17x8” Enkei Racing beadlock wheels
350/85 R17 rally-spec tires suitable for desert terrain
Raised ride height to 290mm with increased suspension travel
▤
Powertrain
RB26 inline-six transformed into a dry sump turbocharged engine
Enhanced cooling via twin roof intake scoops and sidepod ducted radiators
Sequential rear transaxle gearbox relocated rearward for improved weight distribution
Sustainably tuned for endurance with upgraded engine internals
△
Fabrication Notes
Custom widened wheel arches integrate sidepod radiators and LED rally lights
Chassis stretched rearward with reinforced subframe mounts for drivetrain and suspension
Composite body panels chosen for weight reduction and impact resistance
Underbody armor plates fabricated for maximum protection against debris and rocks
×
Design Philosophy
The Dakar Zephyr transforms the iconic 1999 Nissan Skyline GT-R R34 into a rugged desert warrior, purpose-built for the relentless challenges of Dakar-style rally raids. Extensive widebody modifications include massive 190mm front and 230mm rear fender flares, designed to house oversized 350/85 R17 rally tires on beadlock wheels, while reinforced composite bumpers and underbody skid plates provide vital protection against harsh terrain. The chassis is stretched with a 160mm extended wheelbase to accommodate a rear transaxle sequential gearbox and robust armored underbody, enhancing both durability and drivetrain packaging for endurance racing.
Under the hood, the RB26 engine is reinvented as a dry sump turbocharged unit with upgraded cooling fed by distinctive roof scoops and sidepod radiators nestled inside the expanded arches. The suspension is lifted to a 290mm ride height with rally-spec Öhlins dampers to maximize travel and absorption over uneven surfaces. Aerodynamically, the car eschews conventional wings for a functional 280mm roof spoiler integrated into a raised rear canopy, which also houses a spare tire and rally telemetry antennas, balancing airflow stability with practical rally utility.
